Working principle

    The transmission spindle is set in a double-layer spiral blade, the internal spiral will bring the material outward, and the external spiral will leave the material inside. Under the convective movement of the double-layer spiral belt, the material formed a mixed environment with high dynamic efficiency. An inner and outer diameter screw attached to the mixing shaft drives the material in the barrel body, allowing the mixer to flip the material in a wide range of barrels. The mixing unit works in a spiral drive, with an axis near the material performing an axial rotation, from the inside to the side of the advance, an external helix driving the axial rotation of the nearby barrel wall material, and the advance advancing from both directions. Driven by the active shaft for flat movement and rock and other composite movement, to promote the material along the cylinder for circumferential, radial and axial three-way composite movement, so as to achieve a variety of materials flow diffusion, doping, in order to achieve the purpose of high uniformity of mixing.

Features

Ø Good mixing effect: the use of 3D rotation, so that the material in three directions to carry out complex movements, can be more uniform mixing of the various components, to avoid the traditional 2D mixer may appear uneven mixing problems. Mixing uniformity can reach more than 99%, even for the components that have a disparity in weight ratio, it can also achieve a high mixing rate of more than 99.9%.

Ø Strong mixing ability: can be different particle size, density and shape of the material for effective mixing and dispersion, can handle a variety of types of materials, such as powder, granules, pigments, pharmaceuticals, food, colloid, viscous materials, etc., but also for different humidity and viscosity of the material mixing.

Ø High mixing efficiency: able to achieve efficient mixing of materials in a short period of time, greatly shortening the production cycle and improve production efficiency.

Ø Easy to operate: the operation is relatively simple, only need to set the appropriate mixing time and speed and other parameters, you can complete the mixing process. Most of the three-dimensional mixer also has an automatic control function, further improving the ease of operation, reducing the technical requirements of the operator and training costs.

Ø Adjustable: with adjustable mixing parameters, such as rotation speed, tilt angle, etc., can be adjusted according to different materials and process requirements, in order to obtain very good mixing results.

Ø Reasonable structural design: the mixing cylinder body is mostly arc transition, after precision polishing treatment, and more stainless steel material manufacturing, the barrel inside and outside the wall are polished, easy to clean and meet the hygiene requirements, easy to daily cleaning and maintenance, reduce the maintenance cost.

Ø High safety: the equipment is equipped with safety protection devices, such as emergency stop button, overload protection, etc., to ensure safety and reliability in the operation process.


Application scope

Ø  Powdery materials: three-dimensional mixer is very suitable for dealing with a variety of powdery materials, such as fertilizers, pesticides, veterinary drugs, pigments, dyes, food ingredients (such as flour, sugar, milk powder, chocolate, etc.), chemical raw materials, pharmaceuticals, feed and so on. These materials in the mixing process, you can through the unique design of the three-dimensional mixer, to achieve rapid and uniform mixing effect.

Ø Granular materials: in addition to powdered materials, three-dimensional mixer can also deal with a variety of granular materials, such as plastic particles, ceramic particles, metal powder and so on. These granular materials in the three-dimensional mixer can also achieve efficient and uniform mixing.

Ø Viscous and liquid materials: Although the three-dimensional mixer is mainly used to deal with powder and granular materials, but in some specific cases, it can also be used for viscous and liquid material mixing. However, special mixing devices and mixing parameter settings may be required for these types of materials to ensure effective mixing.

    Overall, 3D motion mixing machine can handle a wide range of materials, whether they are powders, granules or viscous and liquid materials, all of which can be efficiently mixed by 3D mixers. This makes three-dimensional mixer has a wide range of applications in pharmaceutical, chemical, food, plastic, rubber, ceramics and many other industries. In the selection of three-dimensional mixer, should be based on the nature of the material, mixing requirements and production capacity and other factors for comprehensive consideration, to ensure that the purchase of the right three-dimensional mixer products.
- Contact us today for more information.
